Electromagnetic Compatibility
Due to the rapid development of technology, the use of electronic devices has increased and disseminated, resulting in industrial accidents such as increased concentration of electromagnetic waves and communication problems and device malfunctions. To prevent these disorders, countries around the world are tightening regulations on electromagnetic disturbances. In line with these regulations, the NTREE Testing Lab. has deployed a variety of testing equipment to provide services for electromagnetic testing.
Test Scope
- Information Technology / Audio & Video / Wireless communication ICT & IoT Device EMC
- Commercial / Science / Medical / Industrial Device EMC
- Household / Lighting & Controller Device EMC
Main Equipment
| Test Space (Test Item) | Facilities | Specification | Test Site |
|---|---|---|---|
| 10m Chamber (RE, RS, EMF, DP) |
EMI (9 kHz ~ 40 GHz) R/S (80 MHz ~ 6 GHz, Max. 10 V/m) |
AC 1Ø, 3Ø Max 480 V / 100 A DC Max. 100 V / 100 A, Included Water Turn Table 3 m, Max. 3 ton |
Gosaek |
| 3m Chamber (R/E, R/S) |
EMI (9 kHz ~ 40 GHz) R/S (80 MHz ~ 6 GHz, Max. 10 V/m) |
AC 1Ø, 3Ø Max 480 V / 100 A DC Max. 100 V / 100 A, Turn Table 1.5 m |
Gosaek |
| 3m Chamber (R/E, R/S, DP) |
EMI (9 kHz ~ 6 GHz) R/S (80 MHz ~ 1 GHz, Max. 10 V/m, 1 GHz ~ 6 GHz, 3 V/m) |
AC 1Ø Max 480 V / 5 kVA DC Max. 60 V / 35 A Turn Table 1.2 m |
Pajang |
| Shield Room #1 (C/E, Click, Harmonic and Flicker) | EMI (9 kHz ~ 30 MHz) |
AC 1Ø, 3Ø Max 480 V / 100 A DC Max. 100 V / 100 A, Included Water |
Gosaek |
|
Shield Room #1 (C/E, Click, Harmonic and Flicker, EMF) |
EMI (9 kHz ~ 30 MHz) |
AC 1Ø Max 480 V / 5 kVA DC Max. 60 V / 25 A |
Pajang |
| Shield Room #2 (EMS) |
ESD (30 kV), EFT (5 kV), Surge(With Telecom surge) (5.5 kV), Voltage Dips, PFM (100 A), C/S (10 V) |
AC 1Ø, 3Ø Max 480 V / 100 A DC Max. 100 V / 100 A |
Gosaek |
| Shield Room #2 (EMS) |
ESD (10 kV), EFT (5.5 kV), Surge(6 kV), Voltage Dips, PFM (30 A), C/S (10 V), Ring Wave (6 kV) |
AC 1Ø Max 300 V / 16A DC Max. 60 V / 10 A |
Pajang |
| Debugging Chamber (R/E) | EMI (9 kHz ~ 1 GHz) |
AC 1Ø, 3Ø Max 480 V / 100 A DC Max. 100 V / 100 A, Turn Table 1.2 M |
Gosaek |
|
AC 1Ø Max 480 V / 5 kVA DC Max. 60 V / 35 A, Turn Table 1.2 M |
Pajang |
Electromagnetic compatibility - RRA(National Radio Research Agency) Designated Test Item
| Electromagnetic compatibility for Wireless Device | Test standard | Applied product | Test site |
|---|---|---|---|
| Common technical requirements | KS X 3124 | Radio equipment and associated ancillary equipment, excluding broadcast receivers | Gosaek/Pajang |
| Short-Range Devices(SRD) operating on frequencies between 9 kHz and 246 GHz | KS X 3125 | Assessment of Short Range Devices (SRD) and ancillary equipment (RFID, Object Detection Sensor etc. | Gosaek/Pajang |
| Private land Mobile Radio(PMR) and ansillary equipment(speech and non-speech) and Terrestrial Trunked Radio(TETRA) | KS X 3127 | Private land Mobile Radio (PMR) and associated ancillary equipment | Gosaek |
| Wireless microphones, similar Radio Frequency (RF) audio link equipment, cordless audio and in-ear monitoring devices | KS X 3130 | Wireless Microphone | Gosaek |
| Broadband Data Transmission systems | KS X 3126 | Bluetooth, 2.4 GHz / 5 GHz WIFI, Zeegbee, 2.4 GHz Wireless etc. | Gosaek/Pajang |
| Cellular Communication Base Station(BS), repeater and ancillary equipment | KS X 3135 | Digital cellular base station equipment, Repeater, Associated ancillary equipment etc. | Gosaek |
| Cellular Communication Mobile and portable(UE) radio and ancillary equipment | KS X 3129 | Digital cellular user equipment(UE), Associated ancillary equipment | Gosaek |
| Product Electromagnetic compatibility | Test standard | Applied product | Test site |
|---|---|---|---|
| Electrical lighting and similar equipment | KS C 9815/KS C 9547 | Indoor lamps, Flood lights, Street lights etc. | Gosaek/Pajang |
| Multimedia Equipment | KS C 9832/KS C 9835 | Broadcasting, Communication, Office equipment, PC, PC peripheral, Adpater etc. | Gosae /Pajang |
| Household applianes, electric tools and similar apparatus | KS C 9814-1/KS C 9814-2 | Home appliances such as refrigerators, washing machines, and vacuum cleaners, Motor tools etc. | Gosaek/Pajang |
| Firefighting Equipment | KS C 9992 | GAS leak alarm, Repeater, Detector, Guidance light, Emergency lighting etc. | Gosaek/Pajang |
| Wireless power transmission Equipment used at home | KS X 3143 | Wireless Charger | Gosaek |
| UPS | KS C 9040-2 | UPS | Gosaek |
| Power Line Communication Equipment | KS X 3141 | Power Line Communication equipment, High/Low | Gosaek |
| Medical electrical equipment | KS C IEC 60601-1-2 | Medical electrical equipment | Gosaek |
| Wired | Test standard | Applied product | Test site |
|---|---|---|---|
| Internet Protocol(IP) based video information processing equiment | KS X 3074 based on terminal device technology | Wired/wireless CCTV, Video surveillance device, NVR, Security cameras etc. | Gosaek/Pajang |
| Electromagnetic fields | Test standard | Applied product | Test site |
|---|---|---|---|
| Electromagnetic fields of Household appliances and similar apparatus with regard to regard to human exposure | Electromagnetic wave strength measurement standard notification | Induction heating (IH) type products, electric blankets, electric mats, electric beds, etc. | Gosaek/Pajang |
